Checklists
confidential
D.2.6
KMaintenance
interval
Spare
part re-
quired
ToolMaintenance work/
Maintenance location
PartNo.
K
VIVIIIIII
Spare
part re-
quired
ToolMaintenance work/
Maintenance location
PartNo.
4 Guide rail of the
pile support plate
Check the function of the limit
switches (safety check).
1st switching point 120 mm
above the base,
2nd switching point 12 mm
above the base.
X X +
5
Maintenance points on the suction head:
Rotary valve Loosen the rotary valve and
remove it.
Clean the valve ducts, the
outer surface and the surface
of the bearing.
Clean, fluf-
fless cloth;
Brush
X X X +
Lifting suckers
Remove and clean 4 lifting
suckers.
Clean the lifting sucker guide.
Check the smooth functioning
of the reinstalled lifting suck-
ers.
Note:
Do not lubricate!
Clean, fluf-
fless cloth;
Brush
X X X +
Check the state of the suction
disks for wear and porosity;
replace suction disks if neces-
sary.
X X X X X X +
Forwarding sucker Remove and clean 5 forward-
ing suckers.
Clean the housing of the for-
warding suckers.
Check the smooth functioning
of the reinstalled forwarding
suckers.
Note:
Do not lubricate!
Clean, fluf-
fless cloth;
Brush
X X X +
6 Capacitive sensor
”Automatic pile
transport change-
over”
Clean the sensor. Brush;
Clean, fluf-
fless cloth
X X X +
7 Suction tape Check the condition of the
suction tape (damage, upright
edges, wear, tension, opera-
tion) and that it is running cor-
rectly.
Adjust the suction tape tension
according to the operating in-
structions, if necessary.
Replace suction tape, if nec-
essary.
X X X X +
