HEIDELBERG Speedmaster CD 102 - Page 143

Checklists
confidential
D.2.9
KMaintenance
interval
Spare
part re-
quired
ToolMaintenance work/
Maintenance location
PartNo.
K
VIVIIIIII
Spare
part re-
quired
ToolMaintenance work/
Maintenance location
PartNo.
4 Rotary valve ”suc-
tion tape vacuum
regulation”
Loosen the rotary valve, and
clean valve ducts, surface of
the rotary valve and of the
bearing.
Center
Clean, fluf-
fless cloth;
Brush
X X X +
5
Maintenance points on the front lays:
Front lays Check state and function of
front lay throw-off.
3 mm Allen
key
X X X X +
6
Maintenance points on the transfer gripper:
Cam lever Lubricate 2 recessed grease
nipples (cam follower).
D.S./O.S.
Grease gun;
Optimol Long-
time PD 2
X X X +
7
Maintenance points on the feed drum:
Gripper shaft
bearing
Lubricating 7 recessed grease
nipples.
Grease gun;
Optimol Long-
ti PD 2
X X X +
Cam lever Lubricate 1 recessed grease
nipple.
O.S.
g
time PD 2
X X X +
8
Maintenance points on the impression cylinder:
Cylinder surface Clean the surface. Soft, lint-free
cloth;
note the ”Ap-
proved clean-
ers” list.
X X X +
Gripper shaft
bearing
Lubricate 2 x 7 recessed
grease nipples per impression
cylinder.
Grease gun;
Optimol Long-
time PD 2
X X X +
Cam lever Lubricate 2 x 1 recessed
grease nipples per impression
cylinder.
O.S.
X X X +
9
Maintenance points on the transfer drum:
Gripper shaft
bearing
Lubricate 2 x 7 recessed
grease nipples per transfer
drum.
Grease gun;
Optimol Long-
time PD 2
X X X +
Cam lever Lubricate 2 x 1 recessed
grease nipple per transfer
drum (cam follower).
O.S.
X X X +
10 Plate cylinder Clean surfaces. Note the ”Ap-
proved clean-
ers” list.
X X X +
