D The suction air at the propelling roller (Fig. 4/5)
D The suction air at the pull plate (Fig. 4/6)
D The suction air at the suction tape (Fig. 4/7)
D The by-pass valve at the suction tape (Fig. 4/8)
1. Press the
Sheet travel
button (Fig. 4/1) in the
banner line. The Paper run menu appears.
2. Press the
Feeder
button (Fig. 4/2). The Paper
run/Feeder menu appears.
3. Press the
Cover guide, air adjustment
button
(Fig. 4/3). The Feeder/Cover guide, air adjust-
ment menu (Fig. 4) appears.
4. Use the ”+” and ”–” buttons (Fig. 4/4) to adjust
the blast air at the blowing/suction nozzle. The
selected value appears above the bar chart.
5. Use the ”+” and ”–” buttons (Fig. 4/5) to adjust
the suction air at the propelling roller. The se-
lected value appears above the bar chart.
6. Use the ”+” and ”–” buttons (Fig. 4/6) to adjust
the suction air at the pull plate. The selected
value appears above the bar chart.
7. Use the ”+” and ”–” buttons (Fig. 4/7) to adjust
the suction air at the suction tape. The selected
value appears above the bar chart.
8. Press the
By-pass valve open/close
button
(Fig. 4/8) to be able to reduce the suction air at
the suction tape further. The button is high-
lighted when the valve is open.
Note
The bypass valve at the suction tape
opens automatically when you select a
printing material thickness of ≤0.1 mm
in the print job data.
9. To exit the menu: Press the
Return
button
(Fig. 4/9), or a button in the banner line.
