Heidi CP55 - Figure 45 Encoding; Figure 46 Magnetic Encoding Advanced Option

28
Partial : Partial print mode. It is printed
partially for the print area only. Printing
speed can be faster than standard mode.
Dither : There are 3 possible selections,
Threshold, Random, and Diffusion Dither.
It is performed with K and KO ribbon only.
(Please select “Diffusion Dither” for high
quality.)
Ribbon Save : Select the split function or
not when K ribbon is installed
K ribbon Split : You can set the both
sides (Front:YMCO, Back:K) to save color
ribbon(YMCKO, HYMCKO, BYMCKO). It is
only activated while printing both sides
option is set.
(5) Encoding
This tap will be shown only when
Magnetic encoder is installed.
Do Encoding :
You can select encoding or
not
Coercivity : You can select the coercivity
to encode
Loco : 300, 600 Oe.
HiCo : 2760 Oe.
SpCo : 4000 Oe.
Auto : Defined automatically
Repeat Count : You can select the retry
count to encoding when encoding is
failed
Figure 45 Encoding
(7) Encoding Advanced Option
Card Stripe Side : The location of
magnetic stripe [Bottom / Top]
Before Flip : Do flipping before encoding
[No / Yes]
After Flip :
Do flipping after encoding [No /
Yes]
Track Advanced Options :
Format : Encoding format (IATA, ABA,
MINS, JISII, Bits Mode)
Figure 46
Magnetic Encoding Advanced Option
