3.2.3 Steering system troubleshooting
Problem
Analyses of trouble
Remedies
Fail to turn
hand-wheel
Pump damaged or breaking down.
Replace
Hose or joint damaged or pipeline blocked.
Clean or replace
Difficult to turn
hand-wheel
The pressure of the safety valve is too low.
Adjust the pressure
Air in steering oil circuit.
Exhaust air
Steering unit fail to recover due to spring
piece damaged or elasticity-insufficient.
Replace spring piece
Oil leakage in the steering cylinder.
Inspect the seal of
the piston
Truck’s snacking
or moving with
oscillation
Spring damaged or elasticity-insufficient.
Replace
Excessive noise
Too low oil level in the oil tank.
Refill oil
Suction pipeline or oil filter blocked.
Clean or replace
Oil leakage
Seals of guide sleeve, pipeline or joint
damaged.
Replace
When the accelerator pedal or brake pedal is pressed, the steering system is in working
state. When eliminating the gas in the steering pipeline, the steering system should be in
working state, turning the steering wheel slowly to the left and right limit positions, so that
the steering wheel can be deflected to the left and right limit positions. (Note: If abnormal
phenomena occur at this time, the power should be switched off immediately to find out the
reasons for eliminating the fault), so that the gas in the pipeline can be exhausted by rotating
left and right repeatedly several times.
4. Electric system
4.1 General description
The standard configuration of the electric system of this series of balanced forklift
trucks is a high performance AC control system, which can realize a silent, high efficient,
smooth and safe control of the truck.
The electrical system is mainly composed of color screen instrument, control system,
traction motor, pump motor, steering motor, battery, control switch, acousto-optic system and
connecting wire harness.
