Page #45 background image
42
voltage. Check battery parameters.
223
DC bus low
1Check battery voltage
2Check battery voltage
3Check if main contactor is connected.
234
Internal supply error
1Restart the key
2Check the load and harness of controller at 5V and
12V port.
156
BMS temperature protection
Check the lithium battery temperature
157
BMS temperature high
Check the lithium battery temperature
158
BMS monocell over-discharge
Need to charge or check CAN communication harness
of lithium battery
159
BMS monocell overvoltage
Check the voltage of single lithium battery
163
BMS overcurrent protection
Check the discharge current of lithium battery
164
BMS charging protection
Check whether the lithium battery under the charging
state
168
BMS current-limiting protection
Check the discharge current of lithium battery
169
BMS current chopping
Check the discharge current of lithium battery
181
BMS communication failure
Check CAN communication harness of lithium battery
161
Instrument CAN communication
failure
Check CAN communication wiring harness and data
between instrument and controller
251
Authentication failed
Use the correct authentication information
252
Primary lock
Unlock primary lock
253
Secondary lock
Unlock secondary lock
254
Remote terminal communication
is down
Check the CAN communication line between the
control system and IDT module
4.6.3 Fault diagnosis of ZAPI
Table 4-4 Fault list of Main pump, main traction
CODE
ALARM
NAME
ACE3 traction master alarms node 2.0and ACE3 pump master alarms
node 5.0
8
WATCHD
OG
Cause:
This is a safety related test. It is a self-diagnosis test that involves the logic between
master and supervisor microcontrollers
Troubleshooting:
This alarm could be caused by a CAN bus malfunctioning, which blinds
master-supervisor communication
17
LOGIC
FAILURE
#3
Cause
A hardware problem in the logic board due to high currents (overload). An
overcurrent condition is triggered even if the power bridge is not driven.
Troubleshooting
The failure lies in the controller hardware. Replace the controller.
18
LOGIC
Cause
