HELI G3 Series User Manual

41
143
Motor temp high
1）Over high temperature of motor
2）Fault of motor temperature sensor or harness
144
Over Current Error
Check if there is short circuit of pump motor and
cable.
145
Charging error
1）Change pre-charging resistance.
2）Low battery voltage
3）Fault of harness
150
DC bus low
1）Check battery voltage;
2）Check the set of battery parameters.
3）Check if the contactor is connected.
151
DC bus high
1）Check battery voltage;
2）Check battery parameters.
152
DC bus high HW detected
1）Check battery voltage;
2）Check the set of driver’s voltage.
153
Internal supply error
1）Check the load and harness of controller at 5V and
12V port.
2）Fault of temperature sensor.
154
Motor speed control error
Check the harness and terminals of motor’s speed
sensor.
201
Short circuit
Phase short circuit or short circuit to B+ or B-
202
ACS temp high
Over high temperature of steering driver
203
Motor temp high
1）Over high temperature of steering motor.
2）Fault of motor temperature sensor or harness
205
Charging error
1）Change pre-charging resistance；
2）Low battery voltage；
3）Fault of harness.
206
DC bus low
1）Check battery voltage.
2）Check battery parameters.
3）Check if the contactor is connected.
207
DC bus high HW detected
1）Check battery voltage.
2）Check battery parameters.
210
Feedback Sensor error
Fault of motor temperature sensor or harness
211
Motor temperature sensor error
Fault of motor temperature sensor or harness
212
ACS temperature sensor error
Over high or low temperature of steering driver
217
Pump Open Drain output error
Check if the harness of driver’s output has short
circuit or open circuit.
218
Motor temperature low
1）Over low temperature of steering motor.
2）Fault of motor temperature sensor or harness
219
Motor temperature high
1）High temperature of steering motor
2）Fault of motor temperature sensor or harness
220
ACS low temperature
Low temperature of controller
221
ACS high temperature
High temperature of controller
222
DC bus high
The voltage of controller is higher than warning
