Ch. 9 TRANSMISSION
9-8
Bearing Replacement
Caution
Never install used bearings. Once bearing
removed， it has to be replaced with new one.
Left crankcase side
Remove the drive shaft and bearing from the left
crankcase.
Remove the drive shaft bearing from the shaft
by outer bearing puller.
Replace the drive shaft bearing with new one by
bearing driver.
Special tool:
Tool number SYM-2341110-REA A6228
Tool name …Bearing driver (6228)
Remove the cir-clip and the park gear.
Remove the counter gear needle bearing.
