HER CHEE ATV-600 - Oil Pump

Ch. 3 LUBRICATION SYSTEM
3-6
Oil Pump
Oil Pump Removal
Remove the recoil starter and the AC
Generator.
Remove the cir clip and take out the oil pump
sprocket.
Make sure that pump shaft can be rotated freely.
Remove 3 screws on the oil pump，and then
remove the oil pump.
