HER CHEE ATV-600 - FUEL SYSTEM

Ch. 4 FUEL SYSTEM
4-1
Mechanism Diagram.............................. 4-1 Vacuum Chamber.................................. 4-6
Precautions in Operation...................... 4-2 Float Chamber........................................ 4-7
Trouble Diagnosis................................. 4-3 Adjustment of idle Speed...................... 4-9
Carburetor Removal / Installation…..... 4-4 Fuel Tank.............................................. 4-10
Air Cut-off Valve..................................... 4-5 Air Cleaner............................................ 4-11
Mechanism Diagram
Fuel Strainer
