Ch. 4 FUEL SYSTEM
4-2
Precautions in Operation
General information
Warning
Gasoline is a low ignition point and explosive materials, so always work in a well-ventilated place
and strictly prohibit flame when working with gasoline.
Cautions
Do not bend off throttle cable. 0amaged throttle cable will make unstable drive-ability.
When disassembling fuel system parts, pay attention to O-ring position, replace with new one as
re-assembly
There is a drain screw in the float chamber for draining residual gasoline.
Do not disassemble air cut valve arbitrarily.
Specification
Item ATV-600
Carburetor diameter 36 mm
I.D. number AM4A
Fuel level 17 mm
Main injector #132
Idle injector #92
Idle speed 1500±100 rpm
Throttle handle
clearance
1-3 mm
Pilot screw 1 1/2
Tools
Special tools
Vacuum/air pressure pump
Fuel level gauge
