Ch. 5 ENGINE REMOVAL
5-1
Precautions in Operation
General Information
The engine has to be supported with special service tools that can be lifted or adjustable.
The following parts can be serviced as engine being mounted on frame:
Carburetor
Drive pulley, drive belt, clutch, and movable drive face assembly.
Start motor.
AC. Generator, oil pump and starter one-way clutch.
Specification
Item Capacity
Replacement 2400 c.c.
Replacement with oil filter changed 2700 c.c.
Engine oil capacity
Disassembly 3000 c.c.
Rear axle gear oil capacity Replacement 150 c.c.
Front differential gear oil
capacity
Replacement 250 c.c.
Engine & radiator 1980 c.c.
Reservoir 420 c.c.
Coolant capacity
Total 2400 c.c.
Torque Value
Engine hanger bolt 7.5-9.5 kgf-m
Exhaust muffler mounting bolt 2.8-3.2 kgf-m
Exhaust muffler connection nut 1.0-1.4 kgf-m
Precautions in Operation……………… 5-1
Engine Installation………….………….. 5-6
Engine Removal………………….…...... 5-2
