Ch. 12 CRANKCASE/CRANKSHAFT
12-4
Remove balance shaft from left crankcase.
Remove crankshaft from left crankcase. Remove
gasket and dowel pins.
Scrape gasket residues off the crankcase contact
surface.
Caution
 Do not damage the contact face of the
gasket. It is better to moisten the gasket residue
for easy scrapping.
Replace crankcase main bearings if necessary.
