Ch. 1 GENERAL INFORMATION
1-11
Chassis：
Locking Position Qty Dia. (mm) Torque (kg-m) Remark
Handlebar upper holder bolt 4 6 2.3
Steering shaft bottom nut 1 14 5.5
Ball joint fixed nut 4 10 4.0
Steering shaft holder bolt 2 8 2.3
Front axle lock nut 2 20 10
Rear axle lock nut 2 20 10
Engine hanger nut 3 10 4.0
Drive gear bolt 5 10 5.5
Driven gear nut 4 10 5.5
Front / Rear suspension arm bolt 8 10 4.5
Front / Rear suspension arm nut 8 10 4.5
Brake lever bolt 2 5 1.0
Brake hose bolt 13 10 2.3
Brake caliper bolt 6 8 4.0
Foot rest flange bolt 6 8 4.0
Exhaust muffler mounting bolt 2 8 2.9
Exhaust muffler connection nut 2 8 2.5
Engine mounting flange nut 2 8 2.5
Engine mounting bracket bolt 5 10 4.0
Wheel nut, front and rear 16 10 5.0
