Ch. 14 BODY COVER
14-9
Tail light cover
Remove
Loosen 6 bolts from the rear carrier.
Lossen the 8 screw from the rear cover.
Loosen 2 screws the screws which
connect to fixed plate.
Remove Tail light cover.
Installation
Install in reverse order of removal procedures.
Caution
Loose battery screw from polar side, never
connect polar and negative with any electric
object.
Remove R/L Tail light coupler.
Loosen rear cover stay screws. (Each side 1
screws)
Caution
Please put the shift lever in the “N” or “p”
position
Warning
It will be very dangerous if not follow this
process that the engine gear will jump position
from ”N” to ”H” or ”R”
