HER CHEE ATV-600 - Page 34

Ch. 2 MAINTENANCE INFORMATION
2-13
NAME Driveshaft BRG. 6328
driver
NAME OUTPUT SHAFT OIL
SEAL 42*52*7
NAME OUTPUT SHAFT OIL
SEAL 38*52*7
NO SYM-9100500-REA A6328 NO SYM-9120900-REA NO SYM-9120800-REA
NAME Water pump oil seal driver NAME WATER PUMP BRG.
6001 driver
NAME Water pump mechanical
seal driver
NO SYM-9120200-REA NO SYM-6001300-REA
A6001
NO SYM-1721700-H9A
NAME CLUTCH COVER BRG.
6207 driver
NAME R COVER OIL SEAL
GUIDE
NAME Lock nut driver
NO SYM-9610000- REA A6207 NO SYM-1133000-REA NO SYM-9020100
NAME Crankcase tool NAME Drive plate fixer NAME MAIN BRG. UP/LWR
40*44*20 driver
NO SYM-1120000-ALL NO SYM-2230000-REA NO SYM-9100110-REA
