12
0x0C
HeadID
The parameter defines the 2-digit TARGETID.
00 … 31
Default : 01
14
0x0E
Sensor polarity for all
presence sensors
Type of sensor signal to start an automatic
read. The setting is applied uniformly for all
sensors.
0 … read process when sensor is covered
1 … read process when sensor is uncovered
Default : 0
18
0x12
Sensor status of all heads
The sensor status of each head is represented by
a bit. The parameter can only be queried
1 … Sensor is assigned
0 … Sensor is not assigned
Example: 0x01 Sensor at Head1 (only one
sensor) is occupied
19
0x13
Data length Autoread
The parameter determines the number of bytes
read from the tag during an automatic read
0 … 136 (max. 17 pages !!)
Default : 8 Datenbytes
20
0x14
Sensor delay time
Delay of the sensor event before a sensor event is
triggered and an automatic read operation is
started.
0 … 255 (1/10s)
Default : 10 (1s)
21
0x15
Readmode sensor triggered
reading
Read mode for reading automatically started by
external input.
00 - read only one page
01 - read until the end character or empty
character2)
02 - read all pages
10 - read only one page with previous sensor
Check1)
11 - read until the end character / empty
character with previous sensor Check 1) 2)
12 - read all pages with previous sensor
Check1)
1) If the Sensor Check (10, 11 and 12) is
activated, the assignment of the potential-free
input is checked before initiating a read / write
process.
When used, the read / write process is started,
otherwise the error message "NOTAG" is sent.
2) 'E' or 'F' in ID bits 0 ... 3 of the read ID
Default : 00 … (read only one page)
