Protocol description ASCII, SECS/HSMS
Customer manual
Version 1.2
LFM LP Reader 15.01.2019
Page 83 of 119
HERMOS AG
Gartenstrasse 19 Tel. +49(9279) 991-0
D-95490 Mistelgau Fax. +49(9279) 991-100
Transponder data can not be read. MID sequence can not be read, as valid ASCII characters
were not found exclusively in the defined MID area. However, the condition of the facilities is
normal.
"CE" Communication error)
Syntax error in message, message format, or value.
"HE" Hardware error
Error in the head of the ID reader / writer, head of the ID reader / writer is deactivated.
"TE" Transponder error, reading / writing unsuccessful (Tag Error)
"NT" No transponder detected in the antenna area. (No Tag)
Where used S18F2, S18F4, S18F8, S18F10, S18F12, S18F14
SSCMD Format: A[max 18]
Description: Specifies an operation to be performed by the subsystem.
Used to distinguish between the various subsystem commands displayed.
"ChangeState" … change status
"GetStatus" … query staus
"Reset" … reset CIDRW
"PerformDiagnostics" … A diagnosis is made.
"ADJUST" … triggers an automatic alignment of the antenna.
"HERMOSDefParams" … Basic setting of the readers parameters.
"SetLED " … Set one of the device LEDs.
CPVAL‘s 1 <LEDStatus>
2 <Timeout>
3 <LEDNo>
Where used S18F13
Status list Format: A[2]
The status list provides information about the system status.
Consists of "PM Information" and the current values of the CIDRW attributes "AlarmStatus", "Operating
Status" and "HeadStatus".
Status list
L,4
<PMInformation>
<AlarmStatus>
<OperatingStatus>
<HeadStatus>
Where used S18F2, S18F4, S18F8, S18F10, S18F12, S18F14
TARGETID Format: A[2 or 4]
The TargetID identifies where a request for action or data is to be applied. The TargetID supports 2
byte and 4 byte format.
