Message examples
*): With TCP / IP transmission in the standard ASC-I1 protocol, the checksum bytes are not transmitted.
Calculation of the XOR checksum:
53 XOR 30 XOR 32 XOR 48 XOR 30 XOR 0D = 24  '2' '4'
Calculation of the addition-checksum:
53 + 30 + 32 + 48 + 30 + 0D = 13A  '3' 'A'
(LSB is used)
ASCII
HEX
Description
‚S'
53
Start character
‚0‘
30
High byte message length
‚2‘
32
Lowbyte message length
‚H‘
48
Message first character: value
‚0‘
30
Message second character: destination address
CR
0D
End character
‚2‘
32*)
Highbyte – Checksum XOR
‚4‘
34*)
Lowbyte – Checksum XOR
‚3‘
33*)
Highbyte – Checksum Addition
‚A‘
41*)
Lowbyte – Checksum Addition
