The following examples are based on the standard ASC-I1 protocol. Different Reader ID's are used
(->Parameter E)
V – Query software version
>> V1
<< v14C464D3449312E32
Command V
Reader-ID 1
Software version '4C464D3449312E32 ‘  ASCII " LFM4I1.2"
I – RF module with connected antenna
>>I210
<<i2
Commandl I
Reader-ID 2
J – RF module Read out tuning value
<< j201
Command J
Reader-ID 2
Data 01 (voting value)
X – Read data (Reading from page 1 of the multipage transponder)
>> X101
<< x1014142434445464748
Command X
Reader-ID 1
Page 01
Data '4142434445464748'  ASCII "ABCDEFGH"
R - Automatic reading on antenna port
<< R1013132333435363738
>> r1
Command R
Reader-ID 1
Page 01
Data '4142434445464748'  ASCII " ABCDEFGH "
W – Write data (Writing page 16 of the multipage transponder)
>> W2103132333435363738
<< w2
Command W
Reader-ID 2
Page 10 (10hex = page 16dec.)
Data '3132333435363738'  ASCII "12345678"
