(1) Exhaust muffler
(3) Pillion step
(Optional)
(4) Front inner box**
(2) Oil level dipstick
(5) Position lamp
(6) Front turn signal lamp
(7) Front Luggage hook
RIGHT SIDE VIEW
6
4
2
9
3
7
(8) USB charger* (inside)
(10) Rear reflex reflector
(9) Center compartment (inside)
8
10
5
1
VEHICLE VIEWS
12
*Accessories and features shown may not be part of standard fitment.
*Optional in LX Model **Optional in VX & LX Models
