Installation can be done in the reverse order of
removal.
Installation
Ÿ Remove the center compartment (4).
Center cover (Removal)
Remove screws 4nos. from the center cover.
32
(1) & (2) Screws
1
2
Body cover (Removal)
Installation can be done in the reverse order of
removal.
Installation
Ÿ Remove the bolt (1).tray fuel sub assy.
Ÿ Remove the center compartment.
NOTE
Park the vehicle on its main stand when
servicing the vehicle with the center
compartment removed.
Ÿ Remove the rear grip bolts (2).
(2) Bolts
2
(3) Screws
3
(1) Bolt
1
