HERO DUET - Instruments and Indicators; Service Reminder

1 Side stand indicator Light glows when the vehicle is parked on the side stand.
2 Turn signal indicator (L) Flashes when left turn signal switch is operated.
3 Speedometer Indicates riding speed.
4 Fuel gauge Indicates approximate fuel quantity (page 15).
5 Turn signal indicator (R) Flashes when right turn signal switch is operated.
6 Reset button Button when long pressed resets tripmeter to zero.
7 Service reminder Displays when a service is due (page 15).
Shows the distance travelled since the last reset
8 Tripmeter
(page 15).
9 Odometer Shows accumulated mileage (page 15).
10 High beam indicator Light glows when headlamp is in Hi Beam.
PART FUNCTIONS
The indicators are in the speedometer panel
above the headlamp. The functions are as
below.
Instruments and Indicators (VX model)
Sl. No.
Description
Function
1
6
54
7
2 3
10
13
9
8
