HERO DUET - Rear View Mirror

Ÿ Remove mounting bolts (3) and screws/
washers(4).
(2) Screws
Installation is in the reverse order of removal.
Ÿ Remove the front cover.
Installation:
3
4
(3) Mounting bolts (4) Screws/washers
2 2
Rear view mirror (Black variant for LX
model)
Removal
Ÿ Loosen the lock nut (2) until it will no
longer turn.
Ÿ Slide the dust cover up (1).
Ÿ Tighten the lock nut.
Ÿ Loosen the rear view mirror approximately 2
turns.
Ÿ Adjust the rear view mirror.
Ÿ Loosen the rear view mirror (3) and
remove it.
Installation
Ÿ Install the rear view mirror until it will
no longer turn.
(1) Dust cover (2) Lock nut
(3) Rear view mirror
1
2
3
NOTE
To open the right side rear view mirror the
threads are to be loosened in clockwise
direction and tightened in counter clockwise
direction.
