HERO DUET - MAJOR COMPONENTS; Brakes: Integrated System and Adjustment

(2) Integrated brake lever
(3) Free play 10-20 mm
2
3
17
(i)
(ii)
A
4
5
(4) Integrated brake arm (5) First adjuster nut
(i) Decrease free play (ii) Increase free play
(i)
(ii)
A
4
5
1
2
F
I
(1) Front brake lever
(3) Free play 10-20 mm
1
3
Measured at the tip of brake levers, free play
should be maintained at 10-20 mm.
Right hand front brake cable (A) on “1 or
F” side
The distance, the front brake lever (1) and
integrated brake lever (2) moves before each
brake starts to engage is called free play (3).
Adjustment
Ÿ Push the integrated brake arm (4) by hand
in the direction as shown.
(Information you need to operate this
vehicle)
Brakes are items of personal safety and should
always be maintained with proper adjustments.
MAJOR COMPONENTS
Brakes (Integrated braking)
When one applies the left lever, front & rear
brakes activate jointly.
