Instruments and Indicators (LX model)
The indicators are in the speedometer panel
above the headlamp. The functions are as
below.
1 Turn signal indicator (L) Flashes when left turn signal switch is operated.
6 Turn signal indicator (R) Flashes when right turn signal switch is operated.
7 High beam indicator Light glows when headlamp is in Hi Beam.
4 Side stand indicator Light glows when the vehicle is parked on the side stand.
5 Fuel gauge Indicates approximate fuel quantity (page 15).
3 Speedometer Indicates riding speed.
2 Odometer Shows accumulated mileage.
Sl. No.
Description
Function
6
1 54
7
2 3
14
