HERO SPLENDOR+ - IGNITION SWITCH FUNCTIONS; Key Position Operations

(1) Ignition switch
(2) Ignition key
(3) Steering lock position
The engine can be started. Turn signal lamp,
Horn, Tail/Stop lamp, Fuel gauge will be
functional.
Key cannot be removed.
Engine cannot be started and no electrical
system will be functional.
Key can be removed
Steering can be locked
Key can be removed
“LOCK”
Key Position
Function
Key Removal
1
23
12
PARTS FUNCTION
IGNITION SWITCH
“LOCK” Position
“ON” ( )
Position
“OFF”( )
Position/
Lock Open
“ON” ( )
“OFF” ( )
