CAUTION
!!
•
Never wash the air cleaner element. Only blow
air for cleaning the dust, as explained. Replace
air cleaner element every 12000 km.
•
Never blow air initially from outside to inside
as the fine dust particles may go deep inside
the element.
34
clamp in housing. Ensure cover lug should
take proper seat on the other side of the
mounting clamp.
Air cleaner drain tube cleaning
Drain the deposit into a suitable container by
pressing the drain tube end. Follow the above
process more frequently when riding in rain or
at full throttle.
(1) Drain tube
1
2
A B
CARBURETOR
Idle speed adjustment
The carburetor is factory pre set in order to
achieve optimum performance and meet
emission standards.
(1) Throttle stop screw (2) Air screw
(3) Throttle position sensor switch
(A) Decrease r (B) Increase /min r/min
However in case of specific requirement of
tuning due to engine stalling in idle speed,
please follow the instructions given here
under:
IDLE SPEED: 1400 100 R± /MIN
•
Adjust idle speed with the throttle stop
screw (1).
•
parkWarm up the engine and the vehicle on
the main stand.
3
If air screw (2) is tampered it affects the
overall performance characteristics of the
vehicle.
Throttle position sensor switch (3) alters the
ignition timing as per the throttle operation
and ensures optimum driving performance.
NOTE
Always adjust the idle speed in i3s switch
“OFF” position.
1
