Air cleaner cleaning
•
Remove the air cleaner element (8) from
the element holder (9).
•
The air cleaner element should be cleaned
by blowing moisture free pressurized air.
7
6
(6) Mounting clamp (7) Air cleaner assembly
33
8
(8) Air cleaner element (9) Element holder
•
Start cleaning by directing the air nozzle
(10) inside the element and cleaning it
by rotating the element about its axis.
•
Now blow the dust from the surface of the
paper element about 50 mm away from
it,with the air nozzle (10) at an angle of
45° and moving it along the paper
pleats.
10
(10) Air nozzle
•
Replace it earlier if it becomes very dirty,
damaged on surface or on the sealing area.
Install the air cleaner element on holder,
insert the air cleaner assembly into the inlet
air duct & press gently to fix the mounting
O
45
50 mm
9
