“ON” ( ) position
At “ON” position (2), fuel will flow from the
tank to the carburetor.
•
For locking, press the lid gently and turn the
key clockwise.
5
4
(4) Filler neck (5) Fuel
Do not park the vehicle under direct sunlight
as it causes evaporation of petrol due to heat
and deterioration of paint gloss due to ultra
violet rays.
Petrol is extremely flammable and is explosive
under certain conditions. Refill in a well
ventilated area with the engine stopped. Do
not smoke or allow flames or sparks in the
area where the petrol is refilled or where
petrol is stored.
FUEL VALVE
The three way fuel valve is on the left side of
the carburetor.
At “OFF” position (1), fuel cannot flow from
the tank to the carburetor. Turn the valve
“OFF” whenever the vehicle is not in use.
“OFF” ( ) position
(1) “OFF” ( ) position
1
17
1
3
(1) Fuel tank cap (2) Ignition key (3) Lid
2
