Savita Oil Technologies Limited.
OIL CAPACITY : 0.95 litre
(a) Engine oil level inspection/Top up
process
•
Bharat Petroleum Corporation Limited.
UPPER
1
2
•
Start the engine, warm it up for serval
minutes and then turn it off.
•
Fill the crankcase through the filler hole with
approx. 0.75 litre of the recommended
grade oil.
•
Remove the tappet inspection cover. Slowly
accelerate and check the engine oil entry
into the cylinder head, engine oil will splash
out from the tappet inspection cover
opening.
•
Wait a few minute until the oil settles down.
•
After the oil has completely drained,
reinstall the drain plug with a new sealing
washer (2).
•
Reinstall the oil level dipstick and check for
oil leaks.
•
If required, add the specified oil up to the
upper level mark. Do not overfill.
•
Remove the oil level dipstick, wipe it clean
and insert without screwing it in.
•
Remove the oil level dipstick and check the
oil level.
•
Quantity of oil to be filled is 0.75 litre
(approx.) during oil change when right
crankcase cover is not removed.
(b) Engine oil replacement/Oil circulation
inspection
•
To drain the oil, remove the oil level dipstick
and drain plug (1) with a sealing washer
(2).
•
Reinstall the oil level dipstick with a new
O-ring.
•
Start the engine and allow it to idle for few
minutes.
(3) Lower level mark
(1) Oil level dipstick (2) Upper level mark
Check engine oil level each day before
operating the vehicle.
Do top up if oil level reaches towards the lower
level mark or every 3000 km whichever is
earlier.
•
Turn the i3s switch to “OFF” position.
•
Start the engine & let it idle for 3-5
minutes.
•
Stop the engine and wait for 2-3 minutes.
The oil level dipstick (1) is on the right
crankcase cover for measuring oil level. Oil
level must be maintained between the upper
(2) and lower (3) level marks on the oil level
dipstick.
•
Park the vehicle on its main stand.
30
LOWER
3
