USER’S MANUAL /
Analog Input
It is possible to select the type of analog input used: RCA (PRE IN) or High Level (SPEAKER IN)
(see section. 7.5.4)
.
I/O Routing
It is possible to change the assignment of the input channels on each output channel and adjust the mixing
percentage
(see section. 7.5.5)
.
Sensitivity
It is possible to calibrate the correct sensitivity of the S8 DSP inputs to adapt them to the signal coming from the
source.
(see section 7.5.6)
. The sensitivity scale will vary according to the type of analog input selected:
RCA (0.8 - 6 Vrms) or Hi level (2.5 - 21 Vrms).
Analog inputs configurations
8
2
2
3
3
1
Analog input equalizer
The S8 DSP software provides an input equalizer, which can be managed by a maximum of 7 parametric
equalization poles per channel, this operation is useful for correcting the outputs of OEM HU sources when
they are equalized.
(see section.7.5.7)
.
1
2
3
