10. TECHNICAL SPECIFICATIONS
POWER SUPPLY
Nominal Power supply voltage / fuse: 7 ÷ 20 VDC 1A
Pulse operating voltage: 5 ÷ 24 VDC
Idling current: 0.34 A
OFF current (ART
TM
= OFF): <80 µA
OFF current (ART
TM
= ON): <80 µA
Remote IN: 6 ÷ 20 VDC (10 mA)
Remote OUT: 4 ÷ 20 VDC (150 mA)
ART - Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable): 1.5 ÷ 7 VDC
SIGNAL STAGE
Distortion - THD @ 1 kHz, 1 VRMS Output: 0.004 %
Bandwidth @ -3 dB: 10 Hz ÷ 40 kHz
S/N ratio @ A weighted, 4 V Output, 1 V Master Input: 100 dBA
S/N ratio @ A weighted, 4 V Output, 1 V Digital IN Input: 112 dBA
Channel Separation @ 1 kHz: 97 dBA
Input sensitivity Pre-In: 0.8 ÷ 6 VRMS
Input sensitivity Speaker-In: 2.5 ÷ 21 VRMS
Input Impedance: 10 kΩ (Pre IN/AUX) 4,7 Ω (Speaker IN)
Max output Level 0,1%THD: 4 V
INPUTS STAGE
Low level (Pre): Ch1 ÷ Ch6 Input/Output Matrix Routing
Hi-Level: Ch1 ÷ Ch6
Digital IN: 1 x Optical S/PDIF; Max 96 kHz / 24 bit; Extra Gain +3 dB, + 6 dB
OUTPUT STAGE
Low level (Pre Out): Ch1 ÷ Ch8;
Output Equalizer 15 poles Parametric EQ: ±12 dB; 20 ÷20 kHz
CONNECTION
From / to personal computer: 1 x micro USB
Bluetooth data connectivity (no audio): BT 5.0 (BLE)
CROSSOVER
Filter type: Full / Hi-Pass / Low-Pass / Band Pass
Filter mode and slope: Linkwitz @ 12 / 24 dB
Butterworth @ 6 / 12 /18 / 24 / 30 dB
Bessel @ 6 / 12 /18 / 24 / 30 dB
Crossover frequencies: 20 ÷ 20 k Hz (120 step)
Phase control: 0° / 180°
EQUALIZER (20 HZ ÷ 20 kHz)
Inputs: Parametric EQ: +12 dB ÷ -12 dB; 7 poles (for each input channel)
Outputs: Parametric EQ: +12 dB ÷ -12 dB; 15 poles (for each output channel)
GENERAL
Memory Preset: 4 x Preset
Memory Preset selection: Through the Control Software or by wire
TIME ALIGNMENT
Distance: 0 ÷ 471,5 cm / 0 ÷ 185.5 in.
Delay: 0 ÷ 13,58 cm
Step: 0,02 ms, 0,7 cm / 0.27 in.
GENERAL REQUIREMENTS
PC connections: 1 x USB 1,1 / 2,0 / 3,0 Compatible or Bloutooth 5.0 BLE
Software / PC requirements: Microsoft Windows (32/64 bit): Windows 8 (USB Only)
Windows 10 (USB and BT BLE)
Mac Os: 10.13 Hight Sierra or later
Minimum mobile device requirements: Android OS 7 or later, iOS 12 or later
Video Resolution with screen resize min. 1024 x 600
Ambient operating temperature range 0° C to 55° C / (32° F to 131° F)
SIZE / WEIGHT
Max size W x H x D (mm/inch): 130 x 37 x 88,3 / 5.12 x 1.45 x 3.48
Weight (kg/lb): 0,66 / 1.45
