Ingress protection IP6K7
Dimensions Height: 75.0 mm
Top/bottom: Φ89.0/93.0 mm
Rated voltage range DC 9 to 36 V
Power consumption ④ 10 W
Operating temperature –20°C to 60°C
Storage temperature –40°C to 85°C
Weight 0.49 kg
DATA I/O
Data transmission Ethernet
100BASE-TX, Slave Mode
Measurements Distance, azimuth angle, and reflectivity
Data points Single Return Ê 640 000 pts/sec
Dual Return Ê 1 280 000 pts/sec
Triple Return Ê 1 920 000 pts/sec
Point cloud data rate Single Return Ê 28.48 Mbps
Dual Return Ê 56.96 Mbps
Triple Return Ê 85.44 Mbps
Clock source GPS/PTP
PTP clock accuracy ⑤ ≤1 μs
PTP clock drift ⑥⑤ ≤1 μs/s
Specifications are subject to change. Please refer to the latest version.
