Hesai XT32M2X User Manual

Appendix B: Absolute time of point cloud data
B.1. Source of absolute time
The lidar retrieves the current absolute time by connecting to an external clock source.
B.1.1. GPS as the clock source
The lidar connects to a third-party GPS module to obtain PPS (pulse-per-second) signal and NMEA sentences.
•
NMEA sentence ($GPRMC or $GPGGA) can be select using either web control or PTC commands.
•
The signal status of GPS PPS and NMEA can be queried using either web control or PTC commands.
•
The timing requirements of PPS and NMEA are shown in Section 2.2.1 Pin description.
•
Each rising edge of the lidar's internal 1 Hz signal triggers a GPS Data Packet. The data format is detailed in Section 3.2 GPS Data Packet.
The absolute time is updated as follows:
NMEA status Date and time (accurate
to the second)
Lidar behavior
Unlocked (Initial) Virtual Since the lidar has not been locked before, it starts counting from a virtual UTC (such as
2000–01–01 00:00:00) using the lidar's internal 1 Hz signal.
-74-
