Symptoms
Points to check
GPS cannot be locked
Make sure that the following conditions are met:
•
GPS receiver is properly connected.
•
PPS signal is connected to the lidar.
•
Destination GPS Port is correctly set (using either web control or PTC commands).
•
The GPS signals satisfy the electrical requirements in Section 2.2 Electrical interface and Figure 11. Connection box
(unit: mm).
Power on again to check if the symptom persists.
