ModelForm FactorFormatFamilyCapacity
HUH721010AL42003.5in.SAS 4Kn ISEUltrastar He1010TB
HUH721010AL42013.5in.SAS 4Kn TCGUltrastar He1010TB
HUH721010AL42043.5in.SAS 4Kn SEUltrastar He1010TB
The enclosure uses the following qualied solid state drives (SSDs):
Table 12: Qualified Solid State Disk Drives
ModelForm FactorFormatFamilyCapacity
HUSMH8020BSS2002.5in.SAS ISEUltrastar
SSD800MH.B
200GB
HUSMR1640ASS2002.5in.SAS ISEUltrastar SSD1600MR400GB
9.2 Enclosure Capacity
Table 13: Fully Populated Enclosure Capacity—HDD
FamilyCapacity per Hard Disk DriveRaw capacity per Enclosure
Ultrastar 7K60004TB (SAS)240TB
Ultrastar 7K60006TB (SAS)360TB
Ultrastar He88TB (SAS and SATA)480TB
Ultrastar He1010TB (SAS)600TB
Table 14: Fully Populated Enclosure Capacity—SSD
FamilyCapacity per Hard Disk DriveRaw capacity per Enclosure
Ultrastar SSD800MH.B200GB (SAS)12TB
Ultrastar SSD1600MR400GB (SAS)24TB
9.3 Partial Population
The 4U60 Storage Enclosure allows for partial population of the enclosure.
SSD Partial Population Rules
The following population rules for SSDs must be followed for a partially populated enclosure to function properly:
• The minimum amount of drives required for the enclosure to function properly is two SDDs.
• Each increase in drive must be done in increments of two.
• Each row that is partially populated with drives must have the population of that row completed with blanks.
• A combination of HDDs and SSDs are allowed, but the rule of increasing capacity must be done by two when SSDs
are involved.
• The remainder of the enclosure, preceding a populated row may remain empty.
• When SSDs are involved, the population of drive slots must be done in the order and positions displayed below.
• Repeat the conguration for each following row.
23
Installation Guide 9 Enclosure Capacity
