1.2 Specification Summary
The following table is a summary of specs relevant and represent a fully congured enclosure:
Table 2: Specification Summary
OperatingNon-operatingCondition (Fully Congured)
5°C to 40°C-30°C to 60°CTemperature
20°C per hour5°C per hourTemperature Gradient
1°C per 125m above 950m1°C per 300m above 3000mTemperature De-rating
8% to 80% non-condensing8% to 80% non-condensingRelative Humidity
30% per hour maximum30% per hour maximumRelative Humidity Gradient
-300m to 3,048m
984 ft. to 10,000 ft.
-300m to 12,000m
-984 ft. to 39,370 ft.
Altitude
3.5g 6ms Pulse vertical shock8g 6ms TrapezoidalShock
Random 0.25 Grms, 5-10Hz
0.05 g sine wave sweep, 10-300Hz
Random 0.6 Grms 10-300HzVibration
Typical: 1.0 KVAN/APower Requirements
Max: 1.8 KVA
Maximum Enclosure Weight (full conguration—HDD): 207.6 lbs./93.71 kg
Minimum Enclosure Weight (without drives): 99.6 lbs./45 kg
Weight
Dimensions (Enclosure): 174.8mm x 424mm x 871.2mm/6.88in. x 16.69in. x
34.3in.
System Dimensions
Dimensions (with CMAs): 174.8mm x 424mm x 1100mm/6.88in. x 16.69in. x
43.3in.
1100mm x 424mm x 174.8mm/43.3in. x 16.69in. x 6.88in.Required Rack Opening Dimensions
Note: The depth of 1100mm is required for the CMA to t and function
properly.
4URack Units (U)
7
Installation Guide 1 Document Summary
