6.
To secure the chassis in the seated position, press and turn the thumb screw counterclockwise until they are tight.
Figure 22: Tightening Chassis Thumb Screws
7.
Repeat the previous step for the remaining side.
11.6 Installing the Hard Disk Drives
To install the hard disk drives (HDD), the following hardware is required:
Note: Ensure that the HDDs are stored in safe area that provides ESD
protection.
Table 23: HDD Hardware
QuantityPart Description
60Hard Disk Drive with Carrier
The following table lists the required tool needed to install the hard disk drives:
Table 24: Required Tools for Installing the HDDs
None
To install the hard disk drives, do the following:
42
Installation Guide 11 Installing the 4U60 Storage Enclosure
