HGST G460-J-12 Installation Guide

The following table lists the required tool needed to attach the CMA brackets to the chassis:
Table 20: Required Tools for Attaching the CMA Brackets
None
To attach the CMA brackets to the chassis, do the following:
1.
Remove the CMA brackets from the box.
Figure 16: Cable Management Assembly Brackets
2.
On the chassis, line up the CMA bracket over the upper set of T-standoffs.
Figure 17: Lining up the Cable Management System Brackets
3.
Press the CMA bracket into the chassis wall and slide the inner rail towards the front of the chassis.
38
Installation Guide 11 Installing the 4U60 Storage Enclosure
