General Operations
22
(green)
Always on More than 4 satellites tracked successfully
Slow flash Loss satellites and try re-tracking
Off
1. mother board error resulting in no data output
while resetting receiver
2. mother board error resulting in no data output
while in static mode
Led displaying in different mode:
1. Work Mode (double click F1 to enter work mode setting,
then single click F1 to choose work modes among static,
rover and base. After that single click power button to
confirm the current setting. If no confirming within 10
seconds, the receiver will automatically confirm the current
settings.）:
● on ○ off
Mode
Satellite led
(green led）
Status led
(green led of the dual-color led）
Base ● ○
Rover ○ ●
Static ● ●
2. Data Link (double click F2 to enter data link setting, then
single click F2 to choose from GSM, UHF, and external, After
that single click power button to confirm the current setting. If
