ASSEMBLY INSTRUCTIONS
PH-300 VERTICAL LIFTING PLATFORM
IM-560en
Vers. 05
Page 29
7 Wait for an hour without touching the threaded rods until the resin hardens
denitely. Tighten the nuts with a maximum par of 3 Nm.
IM560_0906
1:5
> 1h
 3 Nm
15
Flooring
x2
Grower
Washer
85
Ø10
8 Once the built-in xing plate has been attached to the oor, cover it with the ooring
to even out the surface.
