Chapter 9. External View
9-4
9.2.3 Flange 130 Series
External dimensions Key dimensions
Model
L LL LM CB1 CB2 S T U W
Weight
TF05 LF03
269
(315)
211
(257)
160
(206)
132
(53)
180
(226)
19 5 3 5
8.2
(10.4)
KF08
285
(325)
227
(267)
176
(216)
148
(53)
196
(236)
19 5 3 5
8.8
(11.0)
KF10 TF09 LF06
325
(365)
267
(307)
216
(256)
188
(53)
236
(276)
19 5 3 5
11.6
(13.8)
KF15 TF13 LF09
385
(425)
327
(367)
276
(316)
248
(53)
296
(336)
22 6 3.5 6
15.8
(18.0)
CN09 KN06A TN05 LN03
207
(250)
149
(192)
98
(141)
70
(71)
118
(161)
19 5 3 5
5.5
(7.7)
CN15 KN11 TN09 LN06
231
(274)
173
(216)
122
(165)
94
(71)
142
(185)
19 5 3 5
7.0
(9.2)
CN22 KN16 TN13 LN09
255
(298)
197
(240)
146
(189)
118
(71)
166
(209)
22 6 3.5 6
8.5
(10.7)
CN30 KN22 TN17 LN12
279
(322)
221
(264)
170
(213)
142
(71)
190
(233)
22 6 3.5 6
10.0
(12.2)
* Figures in ( ) indicate brake-attached type.
* Use DC 90V for brake input power supply.
(
Dotted lines indicate position of brake-attached connectors
)
<Tape Shaft Detail>
