Chapter 10. Specifications of options
10-1
10. Specifications of options
10.1 AC servo motor cable specifications
10.1.1 Encoder signal cable (Flange 60, 80 Series)
Order code( FCA_□□□□□)
Flexible type Non-flexible type
Flange
3m 5m 10m 20m 3m 5m 10m 20m
60,80 EA03F EA05F EA10F EA20F EA03N EA05N EA10N EA20N
10.1.2 Encoder signal cable (Flange 130,180 Series)
Order code( FCA_□□□□□)
Flexible type Non-flexible type
Flange
3m 5m 10m 20m 3m 5m 10m 20m
130,180,220
FC03F FC05F FC10F FC20F FC03N FC05N FC10N FC20N
