Hikmicro HABROK Series User Manual

Multi-spectrum Binocular User Manual
19
Note
At least one palette should be enabled.
5. Hold to save the settings and exit.
6. Press in live view interface to switch the selected palettes.
Optical
The image of optical channel is displayed in this mode.
White Hot
The hot part is light-colored in view. The higher the temperature is, the
lighter the color is.
Black Hot
The hot part is black-colored in view. The higher the temperature is, the
darker the color is.

Hikmicro HABROK Series Specifications

General

Frame Rate	50 Hz
Pixel Interval	12 μm
Aperture	F1.0
Laser Rangefinder	Yes
Laser Rangefinder Max. Measuring Range	1000 m
Wavelength	905 nm
Protection Level	IP67
Battery Type	Li-ion
Operating Time	6h
Storage Temperature	-40 °C to 70 °C (-40 °F to 158 °F)
