Hikmicro HABROK Series User Manual

Multi-spectrum Binocular User Manual
5
2 Preparation
2.1 Install Battery
2.1.1 Battery Instruction

Remove the battery if the device is not used for a long time.

The external rechargeable battery type is 18650, and the battery size
should be 19 mm × 70 mm. The rated voltage is 3.6 VDC, and the
battery capacity is 3200 mAh.

Charge the battery for more than 5 hours before first use.

To ensure better conductivity, if the battery compartment cover gets
dirty, use a clean cloth to wipe the thread.
2.1.2 Battery Installation
Insert the battery into the battery compartment.
Steps
1. Unlock and open the battery compartment cover.
Figure 2-1 Open the Cover
2. Insert batteries into the battery compartment as the positive and
negative marks indicate.

Hikmicro HABROK Series Specifications

General

Frame Rate	50 Hz
Pixel Interval	12 μm
Aperture	F1.0
Laser Rangefinder	Yes
Laser Rangefinder Max. Measuring Range	1000 m
Wavelength	905 nm
Protection Level	IP67
Battery Type	Li-ion
Operating Time	6h
Storage Temperature	-40 °C to 70 °C (-40 °F to 158 °F)
