Hikmicro HABROK Series User Manual

Multi-spectrum Binocular User Manual
6
Figure 2-2 Install the Battery
3. Close the battery compartment cover and lock it.
Figure 2-3 Close the Cover
2.2 Cable Connection
Connect the device and power adapter with a type-C cable to charge the
device. Alternatively, connect the device and PC to export files.
Steps
1. Lift the type-C interface cover.
2. Connect the device and power adapter with a type-C cable to charge the
device.

Hikmicro HABROK Series Specifications

General

Frame Rate	50 Hz
Pixel Interval	12 μm
Aperture	F1.0
Laser Rangefinder	Yes
Laser Rangefinder Max. Measuring Range	1000 m
Wavelength	905 nm
Protection Level	IP67
Battery Type	Li-ion
Operating Time	6h
Storage Temperature	-40 °C to 70 °C (-40 °F to 158 °F)
