Hikmicro HABROK Series User Manual

Multi-spectrum Binocular User Manual
22
Figure 3-5 Set PIP Mode
Note

If the PIP function is enabled, only the PIP view zooms when adjusting
the digital zoom ratio.

If the PIP function is enabled in thermal mode, the PIP view only
switches between current palette and optical mode; if the PIP function
is enabled in optical mode, the PIP view switches among the selected
palettes and optical mode.
3.10 Adjust Digital Zoom
You can zoom in and out the image by using this function. Press in
the live view interface, the digital zoom ratio switches between 1×, 2×, 4×
and 8×.
Note

When switching the digital zoom ratio, the left interface displays the
actual magnification (Actual Magnification = Lens Optical Magnification
× Digital Zoom Ratio). For example, the lens optical magnification is
2.8× and the digital zoom ratio is 2×, and the actual magnification is
5.6×.

The zoom ratio may vary according to different models. Please take the
actual product for reference.
3.11 Flat Field Correction
This function can correct non-uniformity of display.
Steps

Hikmicro HABROK Series Specifications

General

Frame Rate	50 Hz
Pixel Interval	12 μm
Aperture	F1.0
Laser Rangefinder	Yes
Laser Rangefinder Max. Measuring Range	1000 m
Wavelength	905 nm
Protection Level	IP67
Battery Type	Li-ion
Operating Time	6h
Storage Temperature	-40 °C to 70 °C (-40 °F to 158 °F)
