Hikmicro HABROK Series User Manual

Multi-spectrum Binocular User Manual
34
4. Follow the pop-up instructions to calibrate the compass. See Calibrate
Compass for more information.
Result
After successful calibration, you can see the azimuth angle and elevation
angle displayed on the screen. It is recommended to read the information
when you lay the device horizontally.
To increase the direction accuracy, you can set the magnetic declination
correction. See Magnetic Declination Correction for instructions.
5.7.2 Calibrate Compass
Compass calibration is a must for correction direction display. You need to
calibrate the compass when you enable the function for the first time, or
when the compass is magnetically interfered.
Figure 5-5 Compass Interference
Steps
Call the calibration guide by the following ways.

When you enable compass for the first time, the compass calibration
guide pops up.

When the compass information appears in red, select in the
menu and press to restart calibrating compass.
2. Follow the screen instructions to move and rotate the device.
Figure 5-6 Calibrate Compass
Note

During calibration, keep moving and rotating the device to make sure
that the device faces every possible directions.

Hikmicro HABROK Series Specifications

General

Frame Rate	50 Hz
Pixel Interval	12 μm
Aperture	F1.0
Laser Rangefinder	Yes
Laser Rangefinder Max. Measuring Range	1000 m
Wavelength	905 nm
Protection Level	IP67
Battery Type	Li-ion
Operating Time	6h
Storage Temperature	-40 °C to 70 °C (-40 °F to 158 °F)
