Hikmicro HABROK Series User Manual

Multi-spectrum Binocular User Manual
3
2
Infrared Light
Helps to view target clearly in the dark
environment.
3 & 8
Focus Ring
Adjusts focus to obtain clear targets.
4
Thermal Lens
For thermal imaging.
5
Buttons
To set functions and parameters.
6
Laser
Rangefinder
Measures the distance to the target with
laser.
9
Optical Lens
For optical imaging.
10
Type-C Interface
To connect the device to power supply or
transmit data with a type-C cable.
11
Charging Status
Indicator
 Flashing Red & Green: Error occurred.
 Solid Red: Charging.
 Solid Green: Fully charged.
12 &
15
Battery
Compartment
For holding the battery.
13 &
17.
Neck Strap
Attachment Point
Mounts the neck strap.
14 &
18
Diopter
Adjustment Ring
Adjusts the dioptric setting.
16
Tripod Mount
Mounts the tripod.
Button Description
Table 1-2 Button Description
Icon
Button
Function
Power
 Press: Standby mode/Wake up device.
 Hold: Power on/off.
Capture
 Press: Capture snapshots.
 Hold: Start/Stop recording videos.
Measure
 Press: Turn on laser ranging.
 Double Press: Turn off laser ranging.
 Hold: Correct non-uniformity of display
(FFC).
Mode
Non-Menu Mode:
 Press: Switch palettes.
 Hold: Switch day/night/auto mode.
Menu Mode: Press to move up.
Menu
Non-Menu Mode: Press to enter the menu.
Menu Mode:
 Press: Confirm/Set parameters.

Hikmicro HABROK Series Specifications

General

Frame Rate	50 Hz
Pixel Interval	12 μm
Aperture	F1.0
Laser Rangefinder	Yes
Laser Rangefinder Max. Measuring Range	1000 m
Wavelength	905 nm
Protection Level	IP67
Battery Type	Li-ion
Operating Time	6h
Storage Temperature	-40 °C to 70 °C (-40 °F to 158 °F)
